 Vacuum Controller / 진공 컨트롤러 |
|
|
 |
|
|
|
|
| Cat. No |
Model |
Vacuum Range |
Valve |
| V03-750-121 |
VCB521cv |
1 ~ 1100 mbar |
일체형 |
| Cat. No |
V03-750-121 |
| Model |
VCB521cv |
| Sensor |
Integrated |
| Sensor Type |
Ceramic Sensor |
| Range |
1 ~ 1100 mbar |
| Accuracy |
<±0.3% FS |
| Power Consumption |
15 W |
| RS232 |
Yes, SUB-D Plug 9 Pole |
| Check Valve |
External |
| Connection |
DN 8 Hose Nozzle |
| Power |
90 ~ 264V, 50/60 Hz |
| Size (w X d X h mm) |
195 X 178 X 105 mm |
|
|
|
|
