Adaptors for Swing out Rotors / 스윙로터 아답터

■ Centurion

(0개)

Micro Tube with Cap
Rotor			BRK 1000						BRK 3000
Bucket			B5010			B5250			B2000 / B3000
Shape	용량	Size (mm)	Cat. No.	Model	튜브 수	Cat. No.	Model	튜브 수	Cat. No.	Model	튜브 수
Point	0.5 ml	8×20	C05-79-902	AM405	36	C05-79-904	AM605	40	C05-79-906	AM805	120
Point	1.5 ml	11×38	C05-79-908	AM420	24	C05-79-910	AM620	28	C05-79-912	AM820	84
Point	2.0 ml	11×38	C05-79-908	AM420	24	C05-79-910	AM620	28	C05-79-912	AM820	84
Point	0.2 ml	6×20	C05-79-901	AM402	36	C05-79-903	AM602	48	C05-79-905	AM802	168
Point	0.4 ml	6×30	C05-79-907	AM404	36	C05-79-909	AM604	48	C05-79-911	AM804	168

Plain Tube without Cap
Rotor			BRK 1000						BRK 3000
Bucket			B5010			B5250			B2000 / B3000
Shape	용량	Size (mm)	Cat. No.	Model	튜브 수	Cat. No.	Model	튜브 수	Cat. No.	Model	튜브 수
Round	1 ml	6×45	C05-79-914	AR401	36	C05-79-916	AR601	48	C05-79-918	AR801	168
Round	3 ml	10×60	C05-79-920	AR403	28	C05-79-922	AR603	32	C05-79-924	AR803	96
Round	5 ml	12×75	C05-79-926	AR405	28	C05-79-928	AR605	32	C05-79-930	AR805	96
Round	6 ml	12×82	C05-79-926	AR405	28	C05-79-928	AR605	32	C05-79-930	AR805	96
Round	7 ml	12×100	C05-79-932	AR407	28	C05-79-934	AR607	32	C05-79-936	AR807	96
Round	9/10 ml	14×100	C05-79-938	AR409	24	C05-79-940	AR609	28	C05-79-942	AR809	84
Round	15 ml	17×100	C05-79-944	AR415	8	C05-79-948	AR615	28	C05-79-950	AR815	48
Round	25 ml	24×100	C05-79-952	AR425	8	C05-79-954	AR625	12	C05-79-956	AR825	28
Round	50 ml	34×100	C05-79-958	AR450	4	C05-79-960	AR650	4	C05-79-962	AR850	16
Round	100 ml	45×100	C05-79-964	AR4100	4	C05-79-966	AR6100	4	C05-79-968	AR8100	8
Round	150 ml	52×100	-	-	-	C05-79-970	AR6150	4	C05-79-972	AR8150	4
Round	250 ml	62×100	-	-	-	C05-79-976	AR-Bucket4	4	C05-79-974	AR8250	4

● Note : We cannot be held responsible if the tube manufacturers change design and/or size of the tube.
● Limited capacity with sealed bucket lids (B5419 and B5319).

Bucket for Advanced Centrifuge Rotor
Cat. No.	C05-79-625	C05-79-621	C05-79-633	C05-79-629
Model	B5010	B5250	B2000	B3000
Tube Size Max.	45×100 mm	62×100 mm	98×155 mm	98×170 mm
Rotor	BRK1000	BRK1000	BRK3000	BRK3030

Reducers for Advanced Centrifuge Rotors
Cat. No.	C05-79-707	C05-79-709	C05-79-711	C05-79-713	C05-79-715
Model	RM05	RM10	RM15	RM25	RL10
Tube Size Max.	13×80 mm	16×100 mm	17×120 mm	25×100 mm	16×100 mm
Reduce as	5 ml	10 ml	15 ml	25 ml	10 ml
Rotor	BRK 5324		BRK 5308		BRK 5100

상세 규격 표
Cat. No.	C05-79-717	C05-79-719	C05-79-721	C05-79-703	C05-79-705
Model	RL25	RL50	RL85	RS04	RS05
Tube Size Max.	25×100 mm	35×115 mm	39×115 mm	6×30 mm	8×30 mm
Reduce as	25 ml	50 ml	85 ml	0.2 ~ 0.4 ml	0.5 ml
Rotor	BRK5100			BRK5424
