* 내부 순환기능을 이용하여 Bath 내부 온도를 균일하게 유지
상세 규격 표
Cat. No
Model
Type
Capacity
B04-01-050
COB10
PID Controller
10 L
B04-01-060
COB20
20 L
B04-01-070
COB30
30 L
B04-01-081
CC-127
Cooling Coil 설치, 초기주문시만 가능
상세 규격 표
Cat. No.
B04-01-050
B04-01-060
B04-01-070
Model
COB10
COB20
COB30
Capacity
10 L
20 L
30 L
Controller
Control / Display
PID Control, Autotuning / GLCD (Graphic LCD)
Resolution
0.01℃
Temperature
Range
Ambient +5 to +250℃
Accuracy at 100℃
±0.05℃
Uniformity at 100℃
±0.42℃
±0.85℃
±1.23℃
Pump
Capacity / Pressure
22 L/min / 0.47 bar (6.8psi), Water at 25℃
Dimension
Interior
w240×d300×h195 mm
w290×d500×h195 mm
w300×d450×h230 mm
Exterior
w295×d350×h450 mm
w350×d560×h450 mm
w360×d510×h485 mm
Electric
Power
1 Phase / 220VAC / 60 Hz
Max Consumption
1.1 Kw (5 A)
2.1 Kw (9.6 A)
2.8 Kw (12.8 A)
Other
Drain
1/4” Hose Nipple Male
