● Single-Beam Dual-Lens System
나노 입자부터 마이크로 입자까지 회절 되는 모든 각도의 신호를 정확하게 받을 수 있습니다.
● 자동분산시스템(자동순환, 분산, 급수, 배수, 수위조절 등)이 자동으로 시료를 완벽히 분산하여 시료 측정을 합니다.
|
Size range:
|
Wet Mode: 0.02 - 2,000 μm
Dry Mode: 0.1 - 2,000 μm
| |
Sample Inflow Method:
|
Wet Mode: Built-in automatic
circulating and dispersing system (wet)
Dry Mode: Turbulent flow (dry)
| |
Repeatability:
|
Wet Mode: < 1% (CRM D50)
Dry Mode: < 3% (CRM D50)
| |
Accuracy:
|
Wet Mode: < 1% (CRM D50)
Dry Mode: < 3% (CRM D50)
| |
Measuring Principle:
|
Fraunhofer Diffraction & Mie
Scattering
| |
Laser:
|
Optical fiber semiconductor laser
| |
Operating System:
|
Windows XP / Windows 7 & 8
| |
Connection Port:
|
USB
| |
Photodetectors:
|
90
| |
Measurement Time:
|
1 - 3 minutes per test
| |
Ultrasonic Power:
|
50 W
| |
Maximum Volume:
|
500 mL
| |
Circulating Flow Rate:
|
500 - 2,500 mL/min
| |
Pressure:
|
0.1 - 0.8 Mpa, continuously adjustable
| |
Voltage:
|
110 - 220 VAC, 50/60 Hz
| |
Dimensions:
|
80 x 50 x 41.8 cm
| |
Compliance:
|
ISO 13320
|
|
