Size range of 0.01 to 30 μm maximum;
0.05 to 10 μm typical for low density particles, 0.01 to 2 μm for high
density particles; wide variety of materials dispersed in water and other
solvents
Data System
Windows computer with printer. Real
time graphics and data display, high resolution color (SVGA). Menu driven
data analysis and management system, with single copy license and software
distribution copy.
Drive System
Microprocessor controlled digitally
driven electronic motor. Digital readout for setting and montoring speed.
Speed ocntinously variable from 500 to 15,000 rpm. Speed accuracy and
stability better than + 0.01%. Temperature sensor and digital readout. Dual purpose
integral strobe.
Disc Cavity
Polymethylmethacrylate with stainless
steel hub. Dynamically balanced over range of roatational speeds. Spin fluid
volume from 10 to 40 mL.
