Size Range
|
RH 0.5 nm to 3 μm, sample dependent
|
|
Cell Volume
|
2.5 μL
|
|
Concentration Range
|
0.1 to 100 mg/mL, sample dependent
|
|
Measurement Precision
|
1% typically, depending on
concentration and the size distribution
|
|
Laser
|
Variable up to 35 mW, 638 nm, &
temp. stabilized w/precision power cntr.
|
|
Scattering Angle
|
90°
|
|
Detector
|
Custom avalanche photodiode, APD
|
|
Temperature Range
|
5°C to 90°C
|
|
Computer Interface
|
USB 2.0 & 1.1
|
|
Correlator
|
Brookhaven's TurboCorr, multi-τ,
research grade with 512 channels, covering the equivalent of 107
linearly-spaced channel layout, 100% efficiency, real-time operation over the
entire delay-time range
|
|
Fittings
|
HPLC Inlet/Outlet on front panel; two
sets: batch and flow modes.
|
|
Pressure Range
|
Up to 200 bar (2,940 psi)
|
|
Analog Inputs
|
4 standard. Suitable for use with most
common RI and UV outputs
|
|
Weight
|
5.8 kg
|
|
Dimensions
|
180 x 210 x 380 mm (HWD)
|
|
Power Requirements
|
100/115/220/240 VAC, 50/60 Hz, 45
Watts max
|
|
Environmental Characteristics
|
Temperature: 10°C to 75°C, Humidity:
noncondensing.
|
|
Measurement Modes
|
Software selectable
|
