Specifications
|
|
Model
|
Orion Star A212 Conductivity Benchtop Meter
|
|
Conductivity
|
|
Range
|
0.00 to 3000 mS
|
|
Resolution
|
0.01 uS minimum; 4 significant figures minimum
|
|
Relative Accuracy
|
0.5% reading ¡¾1 digit
|
|
Reference Temperature
|
5 ¡Æ, 10 ¡Æ, 15¡Æ, 20¡Æ, 25¡ÆC
|
|
Compatible Cell Constants
|
0.001 to 199.9
|
|
Calibration Points
|
up to 5
|
|
Resistivity
|
|
Range
|
2 Ohm to 100Meg-Ohm
|
|
Resolution
|
2 ohms-cm
|
|
Relative Accuracy
|
0.5% ¡¾ 1 digit
|
|
Salinity
|
|
Type
|
Practical salinity or natural sea water, multilanguage interface,
direct control of Star stirrer probe 096019 (sold separately)
|
|
Range
|
0.01 to 80.0 ppt NaCl equivalent;
|
|
¡¡
|
0.01 to 42 ppt practical salinity
|
|
Resolution
|
0.01
|
|
Relative Accuracy
|
¡¾ 0.1
|
|
TDS
|
|
Range
|
0 to 200 ppt
|
|
Resolution
|
4 significant digits
|
|
Relative Accuracy
|
¡¾0.5% reading ¡¾1 digit
|
|
TDS Factor Range
|
Linear, 0.01 to 10.00
|
|
Temperature Mode
|
|
Temperature [Range]
|
23¡Æ to 221¡ÆF (-5¡Æ to 105¡ÆC)
|
|
Temperature [Resolution]
|
0.1
|
|
Temperature [Relative Accuracy]
|
¡¾0.1
|
|
Inputs/Outputs
|
|
Inputs
|
8-pin mini-DIN
|
|
Sensor Types
|
2- or 4-cell
|
|
Data Management
|
2000 points with date/time stamp
|
|
Output
|
RS-232, USB
|
|
Display
|
Graphic LCD; simultaneous display of measurement, temperature,
date/time, sample ID, user ID and more
|
|
Power Supply
|
Four "AA" batteries or optional universal AC line voltage
|
|
Environmental operating Conditions
|
|
Relative Humidity
|
5 to 85% noncondensing
|
|
Warranty
|
3-year meter replacement
|
|
Battery Power
|
Four AA (sold separately)
|
|
Battery Life
|
2000 hours
|
