 Glass Microfiber Capsule Filter / 유리섬유 캡슐 필터 |
|
|
 |
|
|
|
|
Capsule Filter, MeissNer®
공통 Specification
* Housing Material : PP
* Filtration Media : PVDF, PP, PTFE, PES
* Media Support Component : PP
* Sealing Method : Thermal Bonding
* Maximum Operating Pressure
* Liquid : 5.2 bar at 38℃
* Gas : 3.4 bar at 38℃
* Operating Temperature Range : 0℃~38℃
* Max. Temperature : 71℃ at 2.4 bar
* Vent Port
- Two Luer-Lock Port for Venting, Draining, Sampling
* Inlet Outlet : 1/4" MNPT Standard
* Optional
- 1" Sanitary Flange (Code : 00)
- 3/8" Horsbarb (Code : 22)
- 1/2" Horsbarb (Code : cc)
- 3/8" FNPT (Code : 55)
- 3/8" MNPT (Code : 66)
* Size : Φ70×h114 mm (Standard, Code : CS)
* Optional
- Φ70×h175 mm (Code : CL)
- Φ57×h83 mm (Code : CF)
- Φ32×h140 mm (Code : CM)
- Φ32×h159 mm (Code : CK)
* Sterilization : Autoclave at 121℃ (60 min), 125℃ (45 min)
* 제조 환경 : Cleanroom, 100% Integrity Tested During Manufacture.
상세 규격 표
| Cat. No |
Model |
Pore |
Size |
| F16-61-500 |
CSRM0.2-442 |
0.2 um |
Φ70×h114 mm (Code : CS) |
|
|
|
|
