* Body : Nickel Plated Brass Barstock
* Bonnet : High Strength Alloy
* Seat : Nylon
* Diaphragm : 316L Stainless Steel
* Seals : PTFE
* Filter : 10 Micron sintered 316L Stainless Steel
* Maximum Inlet Pressure : 25 bar (360 psig), 60 bar (870 psig), 207 bar (3000 psig), 300 bar (4350 psig)*
* Delivery Pressure Range
psig 0-15 psig, 0-22 psig, 0-50 psig, 0-90 psig, 0-150 psig
bar 0-1 bar, 0-1.5 bar, 0-3.5 bar, 0-6 bar, 0-10 bar
* Gauges : 50mm (2") diameter snap-on tamper proof lens
* Ports : 1/4" NPT Female
* Temperature Range : -40¨¬ C to +60¨¬ C (60¨¬ F to 140¨¬ F)
|
|
|
|
