 Multi-Function Conductivity Meter / 정밀형 전도도 미터, Module-type |
|
| Optional Upgrade Expansion Unit |
|
| General Accessory |
|
| Conductivity Cell |
|
|
Cat. No |
Model |
Description |
Unit |
Price
(VAT별도) |
납기 |
재고 |
주문/견적 |
|
|
C19-162-522 |
30014092 |
Conductivity Cell InLab731-ISM |
1/EA |
1,212,000원 |
7 Day |
0 |
|
|
|
C19-162-542 |
30014094 |
Conductivity Cell InLab741-ISM |
1/EA |
1,639,000원 |
7 Day |
0 |
|
|
|
C19-162-555 |
30014097 |
Conductivity Cell Inlab Trace |
1/EA |
2,550,000원 |
7 Day |
0 |
|
|
|
C19-162-558 |
30014099 |
Trace Kit(Sencer & Cell) for Inlab Trace |
1/EA |
4,390,000원 |
7 Day |
0 |
|
|
|
C19-162-560 |
30014098 |
Flow-Cell for Inlab Trace |
1/EA |
2,201,000원 |
7 Day |
0 |
|
|
|
|
 |
|
|
|
|
● 구성
1) S700-Basic : Meter, Conductivity Expansion Unit, 2 Blank Expansion Unit, Eel ctrode Holder, Cover, Manual, PC Software, Test Certificate
2) S700-Kit : “S700-Basic” 기본구성품, InLab® 731-ISM 전극, Guide to Conductivity Measurement, 1회용 Buffer(1413us/cm and 12.88 ms/cm)
3) S700-Trace : “S700-Kit” 기본구성품과 같으나 전극은 Inlab® Trace, With Fol w-Cell and Without Buffer Solution
● 3개의 Module까지 장착 가능하며, 때에 따라서 원하는 Module로 교체 가능함
● Module : PH/MV Expansion Unit, Conductivity Expansion Unit, PH/Ion Expansion Unit, Blank Expansion Unit
● Large Color Display and Intuitive Touch Screen Operation
● GLP Compliant, Including User Management
● The USB, Ethernet and RS232 Interface
● Connection : Barcode Reader, Fingerprint Reader, USB Stick, Network Printer
상세 규격 표
| Cat. No. |
Model |
구분 |
전극 |
| C19-162-210 |
S700-Basic |
Instrument |
X (포함 안됨) |
| C19-162-220 |
S700-Kit |
InLab® 731-ISM |
| C19-162-230 |
S700-Trace |
InLab® Trace (Low Conductivity) |
상세 규격 표
| S700 |
Measuring Range |
Resolution |
Accuracy |
| Conductivity
| 0.001 ~ 999999 uS/cm |
0.001~ 1 |
±0.5% |
| TDS
| 0.001 ~ 1000 g/L, ppt |
0.001~ 1 |
±0.5% |
| Salinity
| 0.01 ~ 80.0 psu, ppt |
0.01 ~ 0.1 |
±0.5% |
| Resistivity
| 0.01 ~ 100.0 ㏁ ·㎝ |
0.0001 ~ 1 |
±0.5% |
| Conductivity
ash
| 0.000 ~ 2022% |
0.001 ~ 1 |
±0.5% |
| Temp. MTC / ATC
| -30℃ ~ 130℃ |
0.1℃ |
±0.1℃ |
| Calibration
| Calibration Points : 1
Temperature Capture : Automatic (Internal and External) and manual
Manual Input of Cell Constant : Yes |
| Regulation
| Pure & Ultra-pure Water : USP/EP Compliant |
| System and
GLP
|
Time and Date : 2 Time Formats, 4 Date Formats
PIN Protection : Login (Password or Fingerprint Reader)
User Management : 4 Groups-Operator, Technician, Expert, Administrator
Measurement Limits : User-Defined
ID Input : User ID, Sample ID, Sensor SN |
| Data
Processing
| Data Storage : At Least 20000 Data Points, 250 Analyses
Print Formats : Summary and User-Defined |
| Connector
| Conductivity Input : Mini-DIN |
Optional Upgrade Expansion Unit
| Cat. No. |
Model |
Description |
| C19-162-850 |
30034472 |
PH/MV Expansion Unit |
| C19-162-860 |
30034473 |
Conductivity Expansion Unit |
| C19-162-870 |
30034471 |
PH/Ion Expansion Unit |
| C19-162-880 |
30034475 |
Blank Expansion Unit |
General Accessory
| Cat. No. |
Model |
Description |
| C19-162-902 |
11120270 |
Power adapter / w Plugs 12V / 10W |
| C19-162-906 |
11124301 |
USB-P25 Printer |
| C19-162-910 |
51192107 |
Fingerprint Reader |
| C19-162-914 |
51302888 |
Rondolino Sample Changer |
| C19-162-918 |
21901297 |
Barcode Reader |
| C19-162-922 |
21901309 |
USB Cable for Barcode Reader |
| C19-162-926 |
51191926 |
USB A-B Cable for LabX↔PC Software |
Conductivity Cell
| Cat. No. |
Model |
Description |
| C19-162-522 |
30014092 |
“Inlab731-ISM” Epoxy, 4 Graphite Pole |
| C19-162-542 |
30014094 |
“Inlab741-ISM” Steel, 2 Steel Pole |
| C19-162-555 |
30014097 |
“Inlab Trace” Titanium, 2 Titanium Pole |
| C19-162-560 |
30014098 |
Flow-Cell for Inlab Trace |
| C19-162-558 |
30014099 |
Inlab Trace Kit, Sensor & Flow Cell |
|
|
|
|
