 Digital Thermomix / 디지털 믹서형 히팅 배스 |
|
|
 |
|
|
|
|
상세 규격 표
| Cat. No |
Model |
온도 범위 |
속도 범위 |
| H04-238-201 |
HCM100-Pro |
-5 ~ 110℃ |
300 ~ 1500 rpm |
| H04-238-205 |
HM100-Pro |
15 ~ 100℃ |
상세 규격 표
| Cat. No. |
H04-238-201 |
H04-238-205 |
| Model |
HCM100-Pro |
HM100-Pro |
| Type |
Heating, Cooling & Mixing |
Heating & Mixing |
| Temperature |
Range |
실온-15℃ ~ 100℃ |
실온+5℃ ~ 100℃ |
| Setting Range |
-5 ~ 110℃ |
15 ~ 100℃ |
| Control Accuracy |
±0.5 ℃ (at 20 ~ 45℃) |
| Uniformity |
Max.±0.5 ℃ (at 20 ~ 45℃) |
| Max.Heating Rate |
5.5 ℃/min |
| Max. Cooling Rate |
2.5℃/min (100℃ ~ Room Temp.)
0.5℃/min (Below Room Temp.) |
- |
| Speed Range |
300 ~ 1500 rpm |
| Mixing Dia. |
Ø3 mm |
| Screen |
LCD Display |
| Program |
6 Program Stages |
Dimension (without Heating
Block) |
w200×d235×h120 mm (without Heating Block) |
| Voltage, Frequency |
100 ~ 120V / 220 ~ 240V, 50Hz / 60Hz |
| Power |
200 W |
|
|
|
|
