Moisture Balance / ¼öºÐ ºÐ¼®±â, MB series |
|
Accessory |
|
|
 |
|
|
|
|
»ó¼¼ ±Ô°Ý Ç¥
| Cat. No |
Model |
¿ë·® |
¼öºÐÀ² ÃÖ¼ÒÇ¥½Ã |
| M11-640-101 |
MB120 |
120g |
0.01% |
| M11-640-111 |
MB200 |
200g |
0.01% |
| M11-640-121 |
MB54 |
50g |
0.001% |
»ó¼¼ ±Ô°Ý Ç¥
| Cat. No |
M11-640-101 |
M11-640-111 |
M11-640-121 |
| Model |
MB 120 |
MB 200 |
MB 54 |
| Measurement Value |
| Readability |
0.01% |
0.01% |
0.00% |
| Repeatability (sd) for initial sample wt.= 2g |
0.10% |
0.10% |
0.05% |
| Repeatability (sd) for initial sample wt.= 10g |
0.03% |
0.03% |
0.02% |
| Evaluation |
| Units of Measurement |
% M, %D, %R (ratio), Gm/Lt, %M Atro, %D Atro |
| Data Storage |
Last 1000 Moisture Determination results |
| Weighing Balance |
| Max. Sample weight |
120 g |
200 g |
50 g |
| Minimum Sample Weight |
0.2 g |
0.2 g |
0.2 g |
| Readability |
0.001 g |
0.001 g |
0.1mg |
| Drying Unit |
| Technology |
Infra Red Halogen |
| Temperature range |
30¨¬ C to 200¨¬ C |
| Temperature increment |
1¨¬ C |
| Heating Profile |
Standard, Gentle, Rapid, Steps, High Temperature |
| User Support |
| Method Memory |
40 |
| Batch Memory |
100 |
| Method Designation |
Alpha Numeric |
| Serial Number |
YES |
| Display |
Graphical LCD display with LED backlit |
| Data Interface |
RS232C Bidirectional, USB, Ethernet, PS2 |
| Print |
GLP / GMP Compliant, User Configurable |
| Miscellaneous |
| Power Supply |
230V / 50Hz or 115V / 60Hz |
| Power Consumption (Watt) |
Max 415 |
Accessory
| Cat. No |
Model |
Description |
| B02-640-330 |
CPR 02 |
Data Printer |
|
|
|
|
