랩캠퍼스(Labcampus) : OverHead Stirrer / 오버헤드 스터러

Digital Overhead Stirrer
Cat. No.	Model	용량	Speed
S08-03-101	MS-BL620D	20 L	80 ~ 2000 rpm
S08-03-105	MS-BL610D	40 L	50 ~ 1000 rpm
S08-03-111	MS-BL606D	80 L	50 ~ 600 rpm
S08-03-115	MS-BL603D	100 L	50 ~ 300 rpm
S08-03-121	MS-BL620D-PK	BL620D Package
S08-03-125	MS-BL610D-PK	BL610D Package
S08-03-131	MS-BL606D-PK	BL606D Package
S08-03-135	MS-BL603D-PK	BL603D Package

● 정회전, 역회전, 자동정/역회전 Timer 설정 가능
● Timer : 99시간 59분
● Auto Reverse : Reverse Time Setting

Analog Overhead Stirrer
Cat. No.	Model	용량	Speed
S08-03-141	MS-BL620	20 L	80 ~ 2000 rpm
S08-03-145	MS-BL610	40 L	50 ~ 1000 rpm
S08-03-151	MS-BL606	80 L	50 ~ 600 rpm
S08-03-155	MS-BL603	100 L	50 ~ 300 rpm
S08-03-161	MS-BL620-PK	BL620 Package
S08-03-165	MS-BL610-PK	BL610 Package
S08-03-171	MS-BL606-PK	BL606 Package
S08-03-175	MS-BL603-PK	BL603 Package

상세 규격 표
Cat. No.	S08-03-101 / S08-03-141		S08-03-105 / S08-03-145		S08-03-111 / S08-03-151		S08-03-115 / S08-03-155
Model	MS-BL620 / MS-BL620D		MS-BL610 / MS-BL610D		MS-BL606 / MS-BL606D		MS-BL603 / MS-BL603D
Stirring Capacity (H₂O)	20 L		40 L		80 L		100 L
Viscosity (Max.)	10,000 mPas (low)		20,000 mPas (low, medium)		50,000 mPas (medium)		100,000 mPas (high)
Motor (output)	Brushless DC motor 60W
Torque (Max.)	2.9 kg · cm (28 Ncm)		5.8 kg · cm (57 Ncm)		9.7 kg · cm (95 Ncm)		19.5 kg · cm (191 Ncm)
Speed Range	80 ~ 2000 rpm		50 ~ 1000 rpm		50 ~ 600 rpm		50 ~ 300 rpm
Speed Controller	Feedback control
Speed Display	Scale	Digital	Scale	Digital	Scale	Digital	Scale	Digital
Rotations	-	1. Right 2.Left(Operation) 3.Auto reverse (Reverse time setting)	-	1. Right 2.Left(Operation) 3.Auto reverse (Reverse time setting)	-	1. Right 2.Left(Operation) 3.Auto reverse (Reverse time setting)	-	1. Right 2.Left(Operation) 3.Auto reverse (Reverse time setting)
Timer	-	99 hr 59 min	-	99 hr 59 min	-	99 hr 59 min	-	99 hr 59 min
Chuck Range	Ø1 ~ 10 mm
Size	w78×d180×h170 mm
Weight	2.8Kg
Electrical Supply	220V 50/60 Hz
