Rack-type Cryosystem / 랙 타입액체 질소 저장 탱크

■ Strong, Lightweight Aluminium Construction
■ High Thermal Efficiency
■ 2 ml용 Racked Storage System
■ Rack과 Cryobox가 기본 포함 되어짐
■ Long Term Storage를 위한 Autofill Accessory Option은 문의 요망
■ Statebourne / BioRack®
■ Bioron

상세 규격 표
Cat. No	Model	용량	Size
C25-07-080	BioRack 750	35 L	Φ480×h710 mm
C25-07-085	BioRack 3000	85 L	Φ646×h738 mm
C25-07-087	BioRack 4800	131 L	Φ646×h913 mm
C25-07-090	BioRack 6000	160 L	Φ648×h1027 mm

상세 규격 표
Cat. No.	C25-07-080	C25-07-085	C25-07-087	C25-07-090
Model	BioRack 750	BioRack 3000	BioRack 4800	BioRack 6000
Capacity	35 L	85 L	131 L	160 L
Evaporation Rate	0.30 L/day	0.63 L/day	0.63 L/day	0.63 L/day
Static Hoding Time	117 day	135 day	208 day	254 day
Weight Empty	19 kg	42 kg	46 kg	64 kg
Weight Full	47 kg	110 kg	152 kg	193 kg
Neck Diameter	120 mm	216 mm	216 mm	216 mm
Roller Base	O	O	O	O
Total 2ml Cryovial Capa.	750 ea	3000 ea	4800 ea	6000 ea

Roller Base
Cat. No	Model	Description
C25-07-520	9902112	for BioRack 750
C25-07-530	9902147	for BioRack 3000, 4800, 6000

Other Accessory
Cat. No	Model	Description	적용
C25-07-560	9702000	Cryoguard low level alarm	BioRack series
C25-07-570	9701321	Temperature logger	BioRack series

● Temperature logger alarm has an 3-way audible alarm for :
Low LN2 Level, High Temperature, Low Battery Power
